BROADBAND 45" BLADE ANTENNA

Crafted with precision and durability in the USA, the Broadband 13" Blade Antenna offers unmatched performance for VHF/UHF handheld applications. This Mil-Spec, robust antenna operates within the 30-512 MHz frequency range, ensuring comprehensive coverage and reliability across various communication scenarios.

Rugged Design and Submersible Capability

Measuring at a length of 45 inches erect, this blade-style antenna combines flexibility with the ruggedness needed for demanding environments. It is designed to withstand submersion up to 20 meters, making it ideal for handheld applications in both terrestrial and aquatic operations.

• Frequency Range: Broadband coverage from 30 – 512 MHz.
• Impedance: 50 Ohms Nominal, ensuring compatibility with a wide array of devices.
• Gain: Gain 30-60 MHz > -20dBi, 60-90 MHz > -10dBi, 90-174 MHz > -6dBi,
  174-512 MHz > -4dBi
• VSWR: Maintained at 3.5:1 Maximum for efficient performance.
• Polarization: Vertical orientation for consistent signal propagation.
• Pattern: Omni-Directional, offering uniform coverage.
• Connector: Equipped with a “TNC” Male connector for easy integration.
• Max Height: 45 inches.
• RF Power Capacity: Handles up to 8 Watt CW, accommodating robust communication needs.
• DC Resistance: Infinite, indicating a purely inductive load.
